Surveying Equipment SOUTH Total Station NTS-362R10 Automatic Total Station

Brand Name : SOUTH

Model Number : NTS-362R10

Place of Origin : China

MOQ : 1 set

Price : ＄1300.00

Payment Terms : T/T, L/C

Delivery Time : 30 work day

Product Name : Robotic Total Station SOUTH NTS-362R10

Customized support : OEM, ODM

Power : lithium battery

Reflectorless : 1000m

Display : LCD Display

Accuracy: Non Prism : 2+2ppm

Accuracy : 2"

Operating time : 8 hour

Contact Now

Surveying Equipment SOUTH Total Station NTS-362R10 Automatic Total Station
Product Overview
Get to know the product better
SOUTH NTS-332 series total stations adopt new technologies such as laser ranging, coding and dual-axis compensation, which greatly reduces the failure rate and improves the efficiency of surveying operations.
All related parts have been redesigned and improved, and the problems of waterproof, moisture-proof and dust-proof have been completely solved.
The distance measuring circuit has been changed from two circuit boards to one circuit board, which is more reliable and easy to maintain. The new height of the station instrument.

Surveying Equipment SOUTH Total Station NTS-362R10 Automatic Total Station
Surveying Equipment SOUTH Total Station NTS-362R10 Automatic Total Station
Surveying Equipment SOUTH Total Station NTS-362R10 Automatic Total Station
Surveying Equipment SOUTH Total Station NTS-362R10 Automatic Total Station
Surveying Equipment SOUTH Total Station NTS-362R10 Automatic Total Station
Surveying Equipment SOUTH Total Station NTS-362R10 Automatic Total Station
Specification

model
NTS-362R10
NTS-362R12
NTS-362R15
Distance measurement (with cooperative targets)
Single prism
5000m
5000m
5000m
Reflector(60mm×60)
1000m
1200m
1500m
accuracy
±(2+2×10¯6·D)mm
Measurement time
Accurate measurement for 0.3 seconds and tracking for 0.1 seconds
Prism free distance measurement (no cooperative target)
Range (Kodak White, 90% Reflectivity)
1000m
1200m
1500m
accuracy
±(3+2×10¯6·D)mm
Measurement time
0.3~3 seconds
Angle measurement
Angle measurement method
Absolute coding angle measurement technology
Disc diameter
79mm
Minimum reading
0.1 "/1"/5 "/10" optional
accuracy
2"
Detection method
Horizontal disc: opposite diameter Vertical disc: opposite diameter
telescope
imaging
Ortho image
Mirror tube length
154mm
Effective aperture of objective lens
45mm
Magnification rate
30X
Field of view angle
1°30'
resolving power
3"
Minimum focusing distance
1.2m
System comprehensive parameters
compensator
Dual axis liquid optoelectronic compensator (compensation range: ± 4/± 6 optional, resolution: 1 ")
Meteorological correction
Automatic correction of temperature and pressure sensors
Prism constant correction
Automatically correct input parameters
Level
Pipe level
30"/2mm
Circular level
8'/2mm
Laser centering device (optical centering device optional)
Brightness adjustment
Level 3 regulation
Accuracy
± 1.5mm (at 1.5m)
Display section
Screen type
320 × 240 dot matrix high-definition and high brightness display screen
Screen size
2.7 inches
digital display
Maximum: 99999999.9999 Minimum: 0.1mm
data transmission
Data interaction interface
RS-232, USB, SD card, Bluetooth
Airborne battery
source
Rechargeable lithium battery, 3100mAH
voltage
DC 7.4V
Continuous working hours
8 hours
Size and weight
size
200mm×190mm×350mm
weight
6.0Kg
