OEM Prismless Total Station Surveying Equipment 1500m Reflectorless

Name: OEM Prismless Total Station Surveying Equipment 1500m Reflectorless
Brand: SOUTH
Price: 1600.00 USD

China OEM Prismless Total Station Surveying Equipment 1500m Reflectorless wholesale

Brand Name : SOUTH

Model Number : NTS-362R15

Place of Origin : China

MOQ : 1 set

Price : ＄1600.00

Payment Terms : T/T, L/C

Delivery Time : 30 work day

Product Name : Robotic Total Station SOUTH NTS-362R15

Customized support : OEM, ODM

Power : lithium battery

Reflectorless : 1500m

Display : LCD Display

Accuracy: Non Prism : 3+2ppm

Accuracy : 2"

Operating time : 8 hour

Contact Now

Surveying Equipment SOUTH Total Station NTS-362R15 Automatic Total Station

Product Description

OEM Prismless Total Station Surveying Equipment 1500m Reflectorless

Specification

model	NTS-362R10	NTS-362R12	NTS-362R15
Distance measurement (with cooperative targets)
Single prism	5000m	5000m	5000m
Reflector(60mm×60)	1000m	1200m	1500m
accuracy	±(2+2×10¯6·D)mm
Measurement time	Accurate measurement for 0.3 seconds and tracking for 0.1 seconds
Prism free distance measurement (no cooperative target)
Range (Kodak White, 90% Reflectivity)	1000m	1200m	1500m
accuracy	±(3+2×10¯6·D)mm
Measurement time	0.3~3 seconds
Angle measurement
Angle measurement method	Absolute coding angle measurement technology
Disc diameter	79mm
Minimum reading	0.1 "/1"/5 "/10" optional
accuracy	2"
Detection method	Horizontal disc: opposite diameter Vertical disc: opposite diameter
telescope
imaging	Ortho image
Mirror tube length	154mm
Effective aperture of objective lens	45mm
Magnification rate	30X
Field of view angle	1°30'
resolving power	3"
Minimum focusing distance	1.2m
System comprehensive parameters
compensator	Dual axis liquid optoelectronic compensator (compensation range: ± 4/± 6 optional, resolution: 1 ")
Meteorological correction	Automatic correction of temperature and pressure sensors
Prism constant correction	Automatically correct input parameters
Level
Pipe level	30"/2mm
Circular level	8'/2mm
Laser centering device (optical centering device optional)
Brightness adjustment	Level 3 regulation
Accuracy	± 1.5mm (at 1.5m)
Display section
Screen type	320 × 240 dot matrix high-definition and high brightness display screen
Screen size	2.7 inches
digital display	Maximum: 99999999.9999 Minimum: 0.1mm
data transmission
Data interaction interface	RS-232, USB, SD card, Bluetooth
Airborne battery
source	Rechargeable lithium battery, 3100mAH
voltage	DC 7.4V
Continuous working hours	8 hours
Size and weight
size	200mm×190mm×350mm
weight	6.0Kg
